Tank container T4 — is a special ISO container designed for the safe transportation and storage of liquid cargo, including petroleum products, as well as certain types of mildly aggressive chemicals and food liquids, provided the appropriate permits are available. Tank containers T4 are used in multimodal transport by road, rail, and sea.
Technical specifications of T4 tank containers
The T4 tank container consists of an AISI316 stainless steel tank built into a rigid metal ISO frame, of 20-foot size. Depending on the purpose, the container may be equipped with thermal insulation, a heating system (steam or electric), additional fittings, and equipment for monitoring operating parameters.
Liquids are discharged using a bottom discharge device or a top unloading valve. To ensure safe operation, the design includes safety elements for pressure control.
Table. Technical specifications of T4 tank containers
| Container specifications | Type 20 tank container ISO (1CC) UN T4 |
|---|---|
| External dimensions | |
| Length, mm | 6,058 |
| Width, mm | 2,438 |
| Height, mm | 2,591 |
| Characteristics | |
| Usable volume, L | 21,000-26,000 |
| Tare weight, kg | 3,520-3,700 |
| Maximum gross weight, kg | 36,000 |
| Maximum payload, kg | 32,300-32,480 |
The T4 tank container complies with international ISO requirements for the transport of liquid bulk cargo.
Advantages of T4 tank containers
T4 tank containers have the following advantages:
- tightness of the container structure and protection of cargo from damage and external influences;
- safe operation due to pressure control systems;
- space saving at terminals and warehouses due to the ability to stack tank containers;
- reduction of logistics costs in international transport;
- long service life with regular maintenance;
- possibility of additional equipping with monitoring systems and control of transport parameters.
The T4 tank container is in demand in the chemical, petrochemical, and food industries, international container shipping, and bulk liquid storage infrastructure. Syrups, wines, dairy products, juices, vegetable oils, diesel fuel, gasoline, kerosene, alcohol, solvents, acetone, and other liquid cargoes are permitted for transport in T4 tank containers according to ADR regulations (European Agreement concerning the International Carriage of Dangerous Goods by Road).
Why buy a T4 tank container from GCS?
Global Container Service offers new or used ISO tank containers T4 with documented proof of technical condition.
Why choose GCS:
- official supplier of container equipment in Ukraine;
- own certified terminal for maintenance, diagnostics, and repair of tank containers;
- specialists with international qualifications;
- sale, rental, and buyback of used T4 tank containers;
- possibility of upgrading equipment according to customer needs.
All tank containers are provided with a CSC (Container Safety Convention) certificate, confirming compliance with international safety requirements.
