A 10-foot blast freezer container is a mobile refrigeration unit designed for rapid food freezing. The equipment is used for deep-freezing products to preserve their structure, weight, and nutritional properties.
The 10-foot blast freezer container allows freezing to be carried out directly at the production or processing site (the deep-freezing speed depends on the type, weight, and initial temperature of the product). After processing, the frozen products are stored or transported in reefer containers.
10-Foot Blast Freezer Container: Design Features
The 10-foot blast freezer container includes a set of main components for intensive heat extraction from the product:
- Thermally insulated body made of sandwich panels with a thickness of 75–100 mm;
- Industrial refrigeration unit with three scroll compressors;
- High-performance air coolers (blast freezers);
- Forced air circulation system;
- Electronic control unit with mode settings;
- Hermetic doors with seals.
Like 10-foot reefer containers, blast freezer containers are available in two modifications: Standard (Dry Van) and High Cube.
Table. Technical Specifications of Blast Freezer Containers
| Container Specifications | Standard (Dry Van) 10ft | High Cube 10ft |
|---|---|---|
| External Dimensions | ||
| Length, mm | 3,010 | 3,010 |
| Width, mm | 2,438 | 2,438 |
| Height, mm | 2,591 | 2,896 |
| Internal Dimensions | ||
| Length, mm | 2,350 | 2,350 |
| Width, mm | 2,250 | 2,250 |
| Height, mm | 2,500 | 2,525 |
| Specifications | ||
| Usable volume, m³ | 13.2 | 13.35 |
| Tare weight, kg | 1,700 | 1,700 |
| Euro pallet capacity, units | 5 | 5 |
| Compressor type | scroll | scroll |
| Refrigerant | R-134a/R-23 | R-134a/R-23 |
| Temperature range, °C | from –20 to -60 | from –20 to -60 |
| Power consumption, kW·h | from 45 to 55 | from 45 to 55 |
| Starting current, A | up to 125 | up to 125 |
10-foot blast freezer containers are used in the agricultural sector, food industry, and product processing, where it is crucial to preserve raw material quality as much as possible after harvest or production.
Advantages of a 10-Foot Blast Freezer Container
Blast freezing technology makes it possible to quickly pass through the critical temperature range without damaging the product's cellular structure.
Advantages of the 10-foot blast freezer container:
- Compact equipment size;
- High mobility;
- Quick installation at the customer's site;
- Reduced logistics costs between processing stages.
The equipment is often used as a blast freezer container for vegetables, berries, fruits, meat, fish, and semi-finished products. Maximum efficiency is achieved with proper loading and air circulation.
Why Buy a 10-Foot Blast Freezer Container from GCS?
Global Container Service offers new and used KLINGE brand blast freezer containers with Copeland compressors.
GCS advantages:
- Selection of freezer containers according to production volumes;
- Comprehensive service maintenance throughout the entire operational life;
- In-house technical facility for all types of container equipment repairs;
- Container delivery across Ukraine using the company's own transport.
The warranty period for a new 10-foot blast freezer reefer container is up to 2 years. The warranty can be extended by agreement.
